MICROCHIP  DM320001  Starter Kit, PICc32, PICC32, Integrated Programmer, Integrated Debugger, Expansion Connector

MICROCHIP DM320001
Technical Data Sheet (23.91KB) EN Zobraziť všetky technické dokumenty

Obrázok slúži len na ilustračné účely. Prosím, pozrite si popis produktu.

MICROCHIP DM320001
Video

Prehľad produktu

The DM320001 is a PIC32 starter kit. The PIC32 starter kit provides the easiest and low cost method to experience the PIC32 microcontroller. From the over 35 source code examples to the getting started project, user can quickly learn Microchip's 32bit family of microcontrollers and development tools. The kit includes everything needed to write, program, debug and execute code on a high performance PIC32 microcontroller. The PIC32 starter kit contains everything needed to experience the high performance PIC32 microcontroller family. The PIC32 starter kit includes an expansion header for adding Microchip's starter kit expansion-boards or for prototyping your own. Host PC requires Windows XP operating system. Microsoft vista support is planned.
  • PIC32MX360F512L 32bit microcontroller
  • Free MPLAB C32 C compiler that compiles up to 64KB of code and no time limits
  • USB connectivity for on-board debugger communications
  • Integrated programmer and debugger
  • Full source based debugging in MPLAB IDE
  • PIC32 running at 72MHz with 512K flash, 32K RAM, 4 channel DMA
  • PIC18LF4550 USB microcontroller for on-board debugging
  • Expansion connector enables addition of Microchip expansion-board
  • 3 user switches and 3 LEDs
  • On-board crystal for precision microcontroller clocking (8MHz)

INFORMÁCIE O PRODUKTE

Silicon Manufacturer:
Microchip
Core Architecture:
PIC
Core Sub-Architecture:
PIC32
Silicon Core Number:
PIC32MX
Silicon Family Name:
PIC32
No. of Bits:
32bit
Kit Contents:
Demo Board, USB Cable
Product Range:
-
Kit Features:
Integrated Programmer & Debugger, Majority of MCU Signal are Present on Connector, USB Powered Board
Features:
Integrated Programmer, Integrated Debugger, Expansion Connector
SVHC:
No SVHC (17-Dec-2015)

Nájsť podobné produkty  zoskupené podľa spoločného atribútu

Aplikácie

  • Industrial;
  • Consumer Electronics;
  • Communications & Networking;
  • Multimedia

Obsah

PIC32 starter kit board, USB mini-B cable

Legislatíva a životné prostredie

Krajina pôvodu:
United States

Krajina, v ktorej boli vykonané posledné úpravy pred uvedením do predaja

V súlade s normou RoHS:
Áno
Č. tarifu:
84733020
Hmotnosť (kg):
.192777
