GU256X32D-K610A8
VFD Display, Dot Matrix, 256 x 32, 14.25mm x 115mm, I2C / Parallel / SPI, 500 mA, 4.5 V to 5.25 V
Potrebujete viac?
| Množstvo | |
|---|---|
| 1+ | 139,970 € |
| 5+ | 132,290 € |
| 10+ | 124,510 € |
INFORMÁCIE O PRODUKTE
Prehľad produktu
The GU256X32D-K610A8 is a Flexible Graphic VFD Module includes the VFD glass, VF drivers, microcontroller, character generation, interface logic and transformerless DC/DC converter. The interface type is selected by a push button on the back of the module. Auto key scanning and general I/O are available on port PA0 to PA7 for user control. Pixel Flexible, use a RISC processor for individual dot/cursor placement with SPI/I²C/RS485/RS232 plus user ports.
- 256 x 32 High brightness dot graphic display
- 4 ASCII fonts (5 x 5, 5 x 7, 10 x 14, 7 x 15)
- Asynchronous, SPI, I²C and parallel interfaces
- 8 user I/O pins with key scanning capability
Aplikácie
Imaging, Video & Vision, Communications & Networking
Upozornenia
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Technické údaje
256 x 32
Dot Graphic
5.25V
-40°C
I2C, Parallel, SPI
No SVHC (14-Jun-2023)
14.25mm x 115mm
4.5V
500mA
85°C
-
Technické dokumenty (1)
Legislatíva a životné prostredie
Krajina, v ktorej boli vykonané posledné úpravy pred uvedením do predajaKrajina pôvodu:Great Britain
Krajina, v ktorej boli vykonané posledné úpravy pred uvedením do predaja
RoHS
RoHS
Certifikát zhody produktu
